R2SD4-10 – Rockford Fosgate – Prime 10″ R2 4-Ohm DVC Shallow Subwoofer

SKU R2SD4-10 Categories , , , Tag

Out of stock

Dealer Login to Order Now

ETA – TBA!

When you have no space for bass, our R2 10″ shallow subwoofer can help satisfy your need for low frequency music. These drivers can fit in tight spaces due to an elevated motor structure that reduces speaker depth. Mica injected polypropylene cones make sure bass notes are clean and accurate. Stamp-cast baskets feature spider venting typically reserved for traditional depth mounted models to keep the motor cool! These shallow subwoofers are optimized for sealed enclosures.

  • 12 AWG compression terminals
  • Anodized aluminum voice coil former
  • Optimized for sealed enclosures
  • Mica injected polypropylene cone
  • Linear spider with embedded 16 AWG tinsel leads
  • StampCast basket with integrated spider venting
  • Integrated PVC trim ring
  • Shallow Motor Assembly
  • 1 Year Warranty
[wpced]

Overview

When you have no space for bass, our R2 10″ shallow subwoofer can help satisfy your need for low frequency music. These drivers can fit in tight spaces due to an elevated motor structure that reduces speaker depth. Mica injected polypropylene cones make sure bass notes are clean and accurate. Stamp-cast baskets feature spider venting typically reserved for traditional depth mounted models to keep the motor cool! These shallow subwoofers are optimized for sealed enclosures.

FEATURES AT A GLANCE

  • 12 AWG compression terminals
  • Linear spider with embedded 16 AWG tinsel leads
  • Optimized for sealed enclosures
  • Mica injected polypropylene cone
  • Shallow Motor Assembly
  • Integrated PVC trim ring
  • Anodized aluminum voice coil former
  • StampCast basket with integrated spider venting
  • 1 Year Warranty

Specification

agnet Weight (oz)
45 oz. 1.28 kg.
Size
10″
Nominal Impedance
Dual 4-Ohm
Mounting Depth
3.417 in. (86 mm)
SPL (dB @ 1w/1m)
82.5
Fs (Hz)
39.3
Vas (Liters)
21.7
Xmax (mm)
8.0
Cutout Diameter
9.125 in. (232 mm)
Re (Ohms)
6.60
Sd (cm2)
333
Le (mH)
4.2
Power Handling (Watts RMS)
200 Watts RMS
400 Watts Max
Voice Coil Diameter
2″ (50 mm)
Shipping Weight
10.588 Lbs. (4.80 kg.)
Speaker Connector
Dual 12 AWG compression
Qts
0.73
Woofer Displacement
0.037 cu. ft. (1.05 Liters)
Qms
7.00
Qes
0.81
CEA-2031 Compliant
CEA-2031 Guidelines
Subwoofer Type
Shallow
Voice Coil Type
Dual Voice Coil
Sealed Box Volume (Vb)
0.7 cu. ft. (19.8 Liters)
Vented Box Volume (Vb)
1.4 cu. ft. (39.6 Liters)

Owners Manual

R2SD4-10
