T1D212 – Rockford Fosgate – Power 12″ T1 2-Ohm DVC Subwoofer

SKU T1D212 Categories , , , Tag

In stock

Dealer Login to Order Now

The Power Series T1D212 Dual 2-Ohm subwoofer builds on innovative new Rockford Fosgate technologies. These bad boys have patented VAST technology that increases surface cone area up to 25% so the T1D212 performs like a much larger woofer over the previous model. The new FlexFit basket not only looks the part but it provides extreme flexibility for extreme installations. Clean, high tech and ready to set off car alarms, the T1D212 is here!

  • Symmetrical dual progressive roll tear resistant poly-cotton spiders
  • Periodic-stitched fatigue resistant tinsel lead wire
  • Proprietary 8 AWG insulated allmetal input spring terminal connection
  • High-temp voice coil with spun-laced Nomex® re-inforcement collar
  • Optimized and matched magnetic and complicance geometry
  • Anodized aluminum heat sinking dust cap
  • Kevlar fiber reinforced paper cone
  • Rigid die-cast aluminum basket
  • Optimized pole piece and spider venting
  • Anodized aluminum voice coil former / copper clad aluminum wire
  • 1 Year Warranty
[wpced]

Overview

The Power Series T1D212 Dual 2-Ohm subwoofer builds on innovative new Rockford Fosgate technologies. These bad boys have patented VAST technology that increases surface cone area up to 25% so the T1D212 performs like a much larger woofer over the previous model. The new FlexFit basket not only looks the part but it provides extreme flexibility for extreme installations. Clean, high tech and ready to set off car alarms, the T1D212 is here!

FEATURES AT A GLANCE

  • Symmetrical dual progressive roll tear resistant poly-cotton spiders
  • Periodic-stitched fatigue resistant tinsel lead wire
  • Optimized and matched magnetic and complicance geometry
  • Proprietary 8 AWG insulated allmetal input spring terminal connection
  • Kevlar fiber reinforced paper cone
  • Anodized aluminum voice coil former / copper clad aluminum wire
  • Rigid die-cast aluminum basket
  • Anodized aluminum heat sinking dust cap
  • High-temp voice coil with spun-laced Nomex® re-inforcement collar
  • Optimized pole piece and spider venting
  • 1 Year Warranty

Specificaton

Size
12″
Voice Coil Diameter
3″ (75.5 mm)
Speaker Connector
Compression Terminal
Nominal Impedance
Dual 2-Ohm
Mounting Depth
6.75 in. (171 mm)
Shipping Weight
33.3 Lbs. (15.10 Kg.)
SPL (dB @ 1w/1m)
85
Qts
0.52
CEA-2031 Compliant
CEA-2031 Guidelines
Qms
4.50
Xmax (mm)
16
Vas (Liters)
55.8
Le (mH)
1.8
Fs (Hz)
28
Magnet Weight (oz)
123 oz. (3.48 kg)
Power Handling (Watts RMS)
800 Watts RMS
1600 Watts Max
Qes
0.59
Cutout Diameter
11.25 in. (285 mm)
Woofer Displacement
0.106 cu. ft. (3.0 Liters)
Sd (cm2)
548
Re (Ohms)
3.25
Subwoofer Type
Standard
Voice Coil Type
Dual Voice Coil
Sealed Box Volume (Vb)
1.25 cu. ft. (35.3 Liters)
Vented Box Volume (Vb)
1.75 cu. ft. (49.5 Liters)
